# NANO-ADL-P-CC-R10

EPIC SBC supports Intel® Alder Lake-P Celeron® 7305 processor with 8GB LPDDR4x memory on board default, with Dual HDMI,DP,IDPM,M.2 A key, M.2 B key, USB 3.2, SATA 6Gb/s, COM, IAUDIO,PCIe x4 for riser card and RoHS

## Základní informace

| Parametr | Hodnota |
| --- | --- |
| Unit | pcs |
| Code 1 | 122514017006 |
| Warranty | 24 |
| Warranty for companies | 24 |
| Brand | IEI |

## Podrobný popis

EPIC SBC supports Intel® Alder Lake-P Celeron® 7305 processor with 8GB LPDDR4x memory on board default, with Dual HDMI,DP,IDPM,M.2 A key, M.2 B key, USB 3.2, SATA 6Gb/s, COM, IAUDIO,PCIe x4 for riser card and RoHS  Specification:Processor: Intel® Alder Lake-P Celeron® 7305, which is an energy-efficient processor with performance for basic applications.Memory: the board has 8 GB of LPDDR4x memory pre-installed on the board, which provides sufficient capacity for smooth system operation.Display Interfaces: The board has dual HDMI, DP (DisplayPort) and IDPM interfaces, allowing up to three independent displays to be connected for multitasking scenarios.M.2 slots: The board features an M.2 A key and an M.2 B key, allowing for storage expansion or additional peripherals.USB 3.2: The board supports fast and powerful USB 3.2 ports for easy connection of external devices.SATA 6Gb/s: The board has a SATA 6Gb/s interface for data storage connections.COM: The board has a COM serial interface for connecting serial devices.IAUDIO: The board has an integrated interface for audio input and output.PCIe x4: The board has a PCIe x4 slot for a riser card, allowing for expanded functionality.

## Soubory ke stažení

* [Katalog NANO-ADL-P_20250617_EN](http://www.elvac.eu/ipc/download/iei/datasheet/NANO-ADL-P_20250617_EN.pdf)
